Engine type V4, four-stroke Engine details
L-twin. Counter-rotating crankshaft.
Power
215.5 HP (157.3 kW)) @ 13000 RPM
Torque
123.6 Nm (12.6 kgf-m or 91.2 ft.lbs) @ 9500 RPM Compression
14.0:1
Bore x stroke
81.0 x 53.5 mm (3.2 x 2.1 inches) Valves per cylinder
4
Fuel system
Injection. Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies.
Fuel control Desmodromic valve control
Cooling system Liquid Gearbox
6-speed Transmission type Chain (final drive) Clutch
Slipper and self-servo wet multiplate clutch with hydraulic control Fuel consumption
7.60 litres/100 km (13.2 km/l or 30.95 mpg) Greenhouse gases
176.3 CO2 g/km. (CO2 – Carbon dioxide emission) Emission details
Euro 5 Exhaust system
4-2-1-2 system with 2 catalytic converter and 2 lambda probes.
Chassis, suspension, brakes and wheels Frame type
Aluminium alloy. Engine is used as a structural chassis element. Trellis subframe.
Rake (fork angle) 24.5°
Trail
100 mm (3.9 inches) Front suspension
Fully adjustable Showa BPF fork 43 mm chromed inner tubes Front wheel travel
120 mm (4.7 inches) Rear suspension
Fully adjustable Sachs unit. Aluminium single-sided swingarm.
Rear wheel travel 130 mm (5.1 inches) Front tire
120/70-ZR17
Rear tire 200/60-ZR17
Front brakes Double disc. ABS. Brembo
Diameter
330 mm (13.0 inches) Rear brakes
Single disc. ABS. Brembo Diameter
245 mm (9.6 inches) Wheels
Cast aluminium 5-spoke. Pirelli Diablo Supercorsa tires.
Seat Dual seat
